Highlights
- Rigid MS Fabricated Frame for minimum angular deflection and reduced vibrations
- Left to right shaft & Shaft runs on 88/12 phos-bronze bushes in oil bath.
- 8 Gibb slide US fabricated and duly stress relieved in two point presses & steel costed slides in single point pressesore used.88-12 phos-bronze bushes are used in guides.
- Wheel is mounted on quill & runs on anti-friction bearings.
- Digital pressure sensor ensures maximum pneumatic clutch life.
- Dynamic Counter Balancer for slides.
- Motorized slide adjustment for all two point presses.
- Combination clutch / brake.
- Hydroulic jam release & thread lock system imported from SANDSUN TAIWAN
- Inverter drive for variable speed.
- PLC based control panel with touch screen HMI- with status and fault message display.
- Programmable Crank angle and SPM Iindicator.
- Total/Preset/ Batch counter.
- Recirculating oil lubrication.
- Misfeed detector sockets.
- Dieheight indicator
- Auto-stock feature incorporate din PLC
